Multi-Socket Power Strip
Technical Data
Scope of Delivery
1 Housing, Al, anodized, natural
5 power sockets (German domestic standard)
1 ON/OFF switch, illuminated, 2-pole
1 System plug
1 System socket
2 fastening brackets
2 T-Slot Nuts V 8 St M5, bright zinc-plated
4 Self-Tapping Screws DIN 7981 C 2.9x25
Fastening elements
Properties
| Line | Work Bench System |
|---|---|
| ESD-safe | No |
| Weight | m = 450 g |
| Delivery unit | 1 set |
Description
Mains connection is via a fixed conventional power cord or a system plug, but it is also possible to connect directly to the mains using Adapter, Socket/Plug (0.0.417.45, max. 16 A).
The Multi-Socket Power Strip can be fastened to profile grooves and all panels – and fits flush with the fastening elements included. The Fastening Sets also enable you to fit the power strip at an angle of 90° or a particularly ergonomic 70°. These sets are then used instead of the fastening elements supplied with the Multi-Socket Power Strips.
The Multi-Socket Power Strip, 5 outlet can also be seamlessly integrated into K56 profiles and Table Uprights (using 0.0.655.27 in the case of Line X profiles).
Assembly Instructions
Variants
Sort by
| 2 more variants in this product family | ||||||
| Edge length X: 51.4 | Edge length Y: 43.7 | Height/depth Z: 358 | Connecting Cable: ✓ | |||
| Edge length X: - | Edge length Y: - | Height/depth Z: - | Connecting Cable: X | |||
Downloads
CAD Data
Accessories
Classification
Classifications are industry-wide product data standards that are used, among other things, to support structured processing in ERP and e-business systems. Do you need the classification data for all item products for your e-procurement system? If so, please don’t hesitate to contact us.
eCl@ss 8.0
27144042
eCl@ss 4.0
27140804
eCl@ss 4.1
27140804
eCl@ss 5.0
27144021
eCl@ss 5.1
27144021
UNSPSC 9.0
39121406
eCl@ss 11.0
27144042
UNSPSC 26.0
39121406
eCl@ss 6.0.1
27143412
eCl@ss 7.1
27144042
UNSPSC 7.0
39121406
Customs tariff number
85365080
