Universal-Fastening Set

Selected variant
Universal-Fastening Set 5/8, bright zinc-plated (0.0.370.34)
Universal-Fastening Set 5/8, bright zinc-plated
0.0.370.34
Show all
Get CAD Data and Downloads

Technical Data

item products are based on different modular dimensions and their associated system grooves.Profiles from Lines 5, 6, 8, 10 and 12 each need corresponding sizes of fasteners.The profiles in Line X feature a Line 8 system groove but have a particularly flat surface withminimum curve radii that make them ideal for building sealed constructions.
item products are based on different modular dimensions and their associated system grooves.Profiles from Lines 5, 6, 8, 10 and 12 each need corresponding sizes of fasteners.The profiles in Line X feature a Line 8 system groove but have a particularly flat surface withminimum curve radii that make them ideal for building sealed constructions.
Components with this symbol meet the requirements of IEC 61340-5-1 and are therefore suitable for use in EPAs (electrostatic protected areas). By complying with the further stipulations of this standard you can use these products to create a safe environment for handling electronic components.
All substances are registered according to the REACH regulation.REACH (Registration, Evaluation, Authorisation and Restriction of Chemicals) ensures that usershave accurate information on the type and properties of operating materials, lubricants, etc.that they might come into contact with.
Components that are RoHS-compliant contain no dangerous substances such as lead or cadmium.EC Directive 2002/95/EC (RoHS 1) restricts the use of certain substances in electronic devices and components.These include batteries, etc.

Scope of Delivery

Universal Fastener 5, die-cast zinc
Hexagon Socket Head Cap Screw DIN 912-M4x18, St, zinc-plated
Special T-Slot Nut 8 Zn M4, zinc-plated

Properties

Article number0.0.370.34
TorqueM = 3 Nm
Lineline 5
Lineline 8
Propertybright zinc-plated
ESD-safeYes
Weightm = 9 g
Delivery unit1 set

Description

Universal-Fastening Set 5/8 from item joins a Line 5 profile to a Line 8 profile to create a right-angled, torsion-resistant connection. The fastener is installed in the Line 5 profile.
The profile can be retrofitted and moved at any time. The Universal Fastener is made of die-cast zinc and requires an installation bore.
Profiles can be retrofitted or moved in existing constructions using universal fastening sets.

Assembly Instructions

Variants

Sort by

Universal-Fastening Set 5, bright zinc-plated

Universal-Fastening Set 5, bright zinc-plated

0.0.370.27
Line:  5Second line:  NoneMaterial:  Steel (bright zinc-plated)Connection type:  Right angledModel:  One-sided
Universal-Fastening Set 5, stainless

Universal-Fastening Set 5, stainless

0.0.437.52
Line:  5Second line:  NoneMaterial:  Stainless steelConnection type:  Right angledModel:  One-sided
Universal-Fastening Set 6, bright zinc-plated

Universal-Fastening Set 6, bright zinc-plated

0.0.419.52
Line:  6Second line:  NoneMaterial:  Steel (bright zinc-plated)Connection type:  Right angledModel:  One-sided
Universal-Fastening Set 6, stainless

Universal-Fastening Set 6, stainless

0.0.441.74
Line:  6Second line:  NoneMaterial:  Stainless steelConnection type:  Right angledModel:  One-sided
Universal-Fastening Set 8, bright zinc-plated

Universal-Fastening Set 8, bright zinc-plated

0.0.026.92
Line:  8Second line:  NoneMaterial:  Steel (bright zinc-plated)Connection type:  Right angledModel:  One-sided
Universal-Fastening Set 8, stainless

Universal-Fastening Set 8, stainless

0.0.444.18
Line:  8Second line:  NoneMaterial:  Stainless steelConnection type:  Right angledModel:  One-sided
Universal-Fastening Set 8 St, bright zinc-plated

Universal-Fastening Set 8 St, bright zinc-plated

0.0.488.60
Line:  8Second line:  NoneMaterial:  Steel (bright zinc-plated)Connection type:  Right angledModel:  One-sided
Universal-Fastening Set 8 St, stainless

Universal-Fastening Set 8 St, stainless

0.0.488.51
Line:  8Second line:  NoneMaterial:  Stainless steelConnection type:  Right angledModel:  One-sided
Universal-Fastening Set 10, bright zinc-plated

Universal-Fastening Set 10, bright zinc-plated

0.0.632.07
Line:  10Second line:  NoneMaterial:  Steel (bright zinc-plated)Connection type:  Right angledModel:  One-sided
Universal-Fastening Set 12, bright zinc-plated

Universal-Fastening Set 12, bright zinc-plated

0.0.003.57
Line:  12Second line:  NoneMaterial:  Steel (bright zinc-plated)Connection type:  Right angledModel:  One-sided
Universal-Butt-Fastening Set 5, bright zinc-plated

Universal-Butt-Fastening Set 5, bright zinc-plated

0.0.370.32
Line:  5Second line:  NoneMaterial:  Steel (bright zinc-plated)Connection type:  ButtingModel:  One-sided
Universal-Butt-Fastening Set 5, stainless

Universal-Butt-Fastening Set 5, stainless

0.0.437.55
Line:  5Second line:  NoneMaterial:  Stainless steelConnection type:  ButtingModel:  One-sided
Universal-Butt-Fastening Set 6, bright zinc-plated

Universal-Butt-Fastening Set 6, bright zinc-plated

0.0.419.53
Line:  6Second line:  NoneMaterial:  Steel (bright zinc-plated)Connection type:  ButtingModel:  One-sided
Universal-Butt-Fastening Set 6, stainless

Universal-Butt-Fastening Set 6, stainless

0.0.441.77
Line:  6Second line:  NoneMaterial:  Stainless steelConnection type:  ButtingModel:  One-sided
Universal-Butt-Fastening Set 8, bright zinc-plated

Universal-Butt-Fastening Set 8, bright zinc-plated

0.0.265.46
Line:  8Second line:  NoneMaterial:  Steel (bright zinc-plated)Connection type:  ButtingModel:  One-sided
Universal-Butt-Fastening Set 8, stainless

Universal-Butt-Fastening Set 8, stainless

0.0.440.94
Line:  8Second line:  NoneMaterial:  Stainless steelConnection type:  ButtingModel:  One-sided
Universal-Butt-Fastening Set 10, bright zinc-plated

Universal-Butt-Fastening Set 10, bright zinc-plated

0.0.632.08
Line:  10Second line:  NoneMaterial:  Steel (bright zinc-plated)Connection type:  ButtingModel:  One-sided
Universal-Fastening Set 5 20, bright zinc-plated

Universal-Fastening Set 5 20, bright zinc-plated

0.0.686.83
Line:  5Second line:  NoneMaterial:  Steel (bright zinc-plated)Connection type:  Right angledModel:  Both sides
Universal-Fastening Set 6 30, bright zinc-plated

Universal-Fastening Set 6 30, bright zinc-plated

0.0.686.81
Line:  6Second line:  NoneMaterial:  Steel (bright zinc-plated)Connection type:  Right angledModel:  Both sides
Universal-Fastening Set 6 60, bright zinc-plated

Universal-Fastening Set 6 60, bright zinc-plated

0.0.686.82
Line:  6Second line:  NoneMaterial:  Steel (bright zinc-plated)Connection type:  Right angledModel:  Both sides
Universal-Fastening Set 8 40, bright zinc-plated

Universal-Fastening Set 8 40, bright zinc-plated

0.0.686.79
Line:  8Second line:  NoneMaterial:  Steel (bright zinc-plated)Connection type:  Right angledModel:  Both sides
Universal-Fastening Set 8 80, bright zinc-plated

Universal-Fastening Set 8 80, bright zinc-plated

0.0.686.80
Line:  8Second line:  NoneMaterial:  Steel (bright zinc-plated)Connection type:  Right angledModel:  Both sides
Universal-Fastening Set 8/5, bright zinc-plated

Universal-Fastening Set 8/5, bright zinc-plated

0.0.370.25
Line:  8Second line:  5Material:  Steel (bright zinc-plated)Connection type:  Right angledModel:  One-sided
Universal-Fastening Set 5/8, bright zinc-plated

Universal-Fastening Set 5/8, bright zinc-plated

0.0.370.34
Line:  5Second line:  8Material:  Steel (bright zinc-plated)Connection type:  Right angledModel:  One-sided
Universal-Fastening Set (Profile St) 8 40, stainless

Universal-Fastening Set (Profile St) 8 40, stainless

0.0.601.03
Line:  8Second line:  NoneMaterial:  Stainless steelConnection type:  Right angledModel:  Both sides
