Plain Bearing Sleeve

Plain Bearing Sleeve

Selected variant
Plain Bearing Sleeve D30/D20 ESD, black similar to RAL 9005 (0.0.670.95)
Plain Bearing Sleeve D30/D20 ESD, black similar to RAL 9005
0.0.670.95
Show all
Get CAD Data and Downloads

Technical Data

item products are based on different modular dimensions and their associated system grooves.Profiles from Lines 5, 6, 8, 10 and 12 each need corresponding sizes of fasteners.The profiles in Line X feature a Line 8 system groove but have a particularly flat surface withminimum curve radii that make them ideal for building sealed constructions.
Components with this symbol meet the requirements of IEC 61340-5-1 and are therefore suitable for use in EPAs (electrostatic protected areas). By complying with the further stipulations of this standard you can use these products to create a safe environment for handling electronic components.
All substances are registered according to the REACH regulation.REACH (Registration, Evaluation, Authorisation and Restriction of Chemicals) ensures that usershave accurate information on the type and properties of operating materials, lubricants, etc.that they might come into contact with.
Components that are RoHS-compliant contain no dangerous substances such as lead or cadmium.EC Directive 2002/95/EC (RoHS 1) restricts the use of certain substances in electronic devices and components.These include batteries, etc.

Properties

Article number0.0.670.95
LineLine D30
ESD-safeYes
Weightm = 6 g
Delivery unit1 pce.
MaterialPOM, ESD
Colourblack similar to RAL 9005

Description

Plain Bearing Sleeve D30/D20 ESD ensures that a Profile Tube D30 will slide smoothly inside a Profile Tube D40/D30. This makes it ideal for building manual telescopic solutions.

Assembly Instructions

Variants

Sort by

Plain Bearing Sleeve D40/D30 ESD, black similar to RAL 9005

Plain Bearing Sleeve D40/D30 ESD, black similar to RAL 9005

0.0.665.63
Accessory function:  SlideDiameter:  ø 40 mmWith anti-torsion device:  XInside diameter:  31Diameter:  40
Plain Bearing Sleeve D40/D30 ESD with anti-torsion feature, black similar to RAL 9005

Plain Bearing Sleeve D40/D30 ESD with anti-torsion feature, black similar to RAL 9005

0.0.676.03
Accessory function:  SlideDiameter:  ø 40 mmWith anti-torsion device:  ✓Inside diameter:  31Diameter:  40
Plain Bearing Sleeve D30/D20 ESD, black similar to RAL 9005

Plain Bearing Sleeve D30/D20 ESD, black similar to RAL 9005

0.0.670.95
Accessory function:  GuideDiameter:  ø 30 mmWith anti-torsion device:  ✓Inside diameter:  21Diameter:  30

Downloads

CAD Data

Classification

Classifications are industry-wide product data standards that are used, among other things, to support structured processing in ERP and e-business systems. Do you need the classification data for all item products for your e-procurement system? If so, please don’t hesitate to contact us.
eCl@ss 8.0
23050191
eCl@ss 4.0
23050402
eCl@ss 4.1
23050402
eCl@ss 5.0
23050107
eCl@ss 5.1
23050107
eCl@ss 6.0.1
23050107
eCl@ss 7.1
23050191
eCl@ss 11.0
23050191
UNSPSC 9.0
31162703
UNSPSC 7.0
31162703
Customs tariff number
39269097
