Table Column Set 2 E HD ESD 230V (0.0.701.52)
Table Column Set 2 E HD ESD 230V
0.0.701.52
Show all
633 1.033
On request
* Mandatory information
Get CAD Data and Downloads

Technical Data

item products are based on different modular dimensions and their associated system grooves.Profiles from Lines 5, 6, 8, 10 and 12 each need corresponding sizes of fasteners.The profiles in Line X feature a Line 8 system groove but have a particularly flat surface withminimum curve radii that make them ideal for building sealed constructions.
Work Bench System
Components with this symbol meet the requirements of IEC 61340-5-1 and are therefore suitable for use in EPAs (electrostatic protected areas). By complying with the further stipulations of this standard you can use these products to create a safe environment for handling electronic components.
All substances are registered according to the REACH regulation.REACH (Registration, Evaluation, Authorisation and Restriction of Chemicals) ensures that usershave accurate information on the type and properties of operating materials, lubricants, etc.that they might come into contact with.
Components that are RoHS-compliant contain no dangerous substances such as lead or cadmium.EC Directive 2002/95/EC (RoHS 1) restricts the use of certain substances in electronic devices and components.These include batteries, etc.
This component is suitable for use in cleanroom applications. It has either been certified to ISO 14644-1 (particle emissions), ISO 14644-15 (outgassing) or another regulation pertaining to cleanroom technology, or it is identical to articles that have been certified. Alternatively, the component can be specially accredited for use in clean production due to its function or design.

Scope of Delivery

2 columns, Al, anodized, natural, with 1.7 m cable
Control unit with 3 m mains cable
Manual controls, 3 positions storable, digital height gauge with 2 m cable
Nominal voltage: 230V~ 50/60 Hz
Total lifting force: 6000 N
Permitted bending moment:
Mbx stat. 1200 Nm, Mby stat. 450 Nm
Mby dyn. 550 Nm, Mby dyn. 200 Nm
Lifting speed: max. 9 mm/s
Duty cycle: 5 %
Temperature range: -5°C to 40°C
Protection: IP30 (columns, manual controls), IP20 (control unit)
Conformity: CE
Installation guide

Properties

Article number 0.0.701.52
Line Work Bench System
Line line 8
ESD-safe Yes
Weight m = 26,5 kg
Ambient temperature (during operation) -5 °C ... +40 °C
Supply voltage . = 230V~ 50/60 Hz
Delivery unit 1 set
Maximum travelling speed Vmax = 9 mm/s
Stroke max. Hmax = 400 mm
Max. load-carrying capacity F = 6000 N
cleanroom suitability Yes

Description

The Table Column Set 2 E HD ESD 230V from item offers an electrical height-adjustment solution for work benches with heavy loads. The two powerful and ESD-safe lifting columns enable the construction of customised heavy-duty workstations.
Height-adjustable table columns provide an ergonomic working position for users of different heights, as well as making it easy to switch between sitting and standing work.
The table switch panel with digital height display ensures users can select their desired working height precisely. Thanks to the memory function, three height positions can be stored on the controller and implemented on the bench automatically, at the touch of a button.
Using the Cantilever Foot Set 8 (0.0.676.18), two item Table Columns suffice to design the base assembly of a height-adjustable work bench. With the Double Cantilever Foot Set 8 (0.0.676.19), two opposing table tops can be used on a single Table Column Set.
The Table-Top Support Set 8 520x100 (0.0.676.17) attaches the table top to two Item Table Columns of a work bench. The sturdy beams also serve to mount Profiles 8 as supporting struts to reinforce the table top.
When an odd number of table columns are used, Table-Top Support 8 520x100 (0.0.703.60) can be ordered individually.

Variants

Sort by

Table Column Set 2 E HD ESD 230V

Table Column Set 2 E HD ESD 230V

0.0.701.52
Power supply:  230 V
Table Column Set 2 E HD ESD 120V

Table Column Set 2 E HD ESD 120V

0.0.722.06
Power supply:  120 V

Downloads

CAD Data

"Table Column Set 2 E HD ESD 230V" is a product-set and contains the same article 2 times. The representation in the CAD data therefore differs from the actual BOM content.
